Submersible Pumps
Submersible pumps are the most popular style of pumps used in homes and gardens. They are an efficient and effective way of pumping water. Submersible Pumps must be submersed in water. They are regularly referred to as ‘sump pumps’ because they are usually placed inside a sump or chamber.
How to choose a Submersible pump:
- Firstly, evaluate the size of the area or how much water needs to be removed The main difference with the pump models are how quickly they can pump water (the flow rate). For example the BPS-80 model has a flow rate of 40ltrs a minute and the BCV3700-80 model has a flow rate of 1500ltrs a minute.
- Select the correct pump for the liquid to be pumped, i.e. clean water, dirty water, salt water etc.
- Will the pump be running 24-7? If so you may wish to look at our pond pumps which are specially designed for this.
- Select the pump that clears the water to a depth you require. Puddle pumps can pump water as low 1mm whereas submersible pumps tend to be around 30mm.
- Finally, assess how far you would need to pump the water away and ensure an adequate ‘head’. Per 10m of horizontal pumping, you can assume a 1m head loss.
- When you have worked this out you should find it easy to find the right pump for the job.
If you are still unsure, you can give us a call and speak to one of our pump experts who will be more than happy to help you.
Submersible Pump Uses:
Submersible pumps, or sump pumps are great for pumping groundwater, seepage or rainfall, and are recommended for flood defence schemes. Submersible pumps can be effectively used in construction or site drainage enabling contractors to continue working in wet weather. The main advantage to submersible pumps are that they generally do not require priming as they are already submersed in the water. The submersible pumps listed are also electric, so they can be used internally or externally (unlike engine driven pumps).
Submersible pumps each have different specialised uses and applications include:
- Well or borehole pumping
- Site drainage
- Water transfer
- Flood protection
- Waste water removal
- Water features for ponds
Pumps come in many different variations for the removal of different liquids, including: clean and dirty water, salt water and chemicals. We have a broad range available, with 13 different series of submersible pumps in this category.
Submersible or sump pumps are often highly recommended for flood defence uses as they are small and easily stored, quick to use and are extremely effective at pumping water.
Groundwater and flood water can be pumped away effectively with a submersible pump, helping to keep an area dry. Submersible pumps tend to have higher flow rates than puddle pumps, however generally they shouldn’t run dry and should be installed in a chamber (unless otherwise specified).
They can be wired in permanently and if the pump is automatic it will trigger when necessary, making it ideal for use in a passive flood defence scheme. Unlike engine driven pumps they do not have to ‘suck’ water up through a pipe as they are submerged in the water; making them quick and easy to use.
Sump Pumps:
In permanent installations, submersible pumps are often used in sumps as the pumps should not run dry. Sumps are chambers in the ground which are designed to fill with water, meaning the pump is submersed. If you do not have a chamber (and don’t wish to install one) but require water pumping to a low-level you need a special type of submersible pump, called a Puddle Pump. Puddle Pumps are specially designed for this and we have a separate section for these pumps. Sump Pumps can be installed either internally to manage flooding, or externally to manage a drainage system or help control groundwater flooding. Groundwater flooding is poorly understood, but it happens when high rainfall fills aquifers in the ground. Groundwater flooding can be mitigated against by installing a sump pump– helping to keep property dry.
How do Submersible/Sump Pumps work?
Submersible Pumps have 5 main components: The inlet, impeller, electric motor, housing and outlet.
Submersible pumps use a sealed electric motor, to convert electrical energy into kinetic energy. The motor spins at high speed, and has an impeller attached to the end of it on a shaft. As the impeller spins it creates a centrifugal force. As a result, a pressure difference occurs, which draws water in through the inlet of the pump, and pushes it under pressure out of the outlet, which can be connected to a pipe.
It is important to note that different submersible pumps have different uses, and you need to select the most suitable pump for your requirements.
Submersibles are designed to work whilst being fully submersed in liquid. This ensures the pump is kept cool meaning it can run for extended periods of time without supervision. Our range or submersible pumps are very reliable and automatic versions are often only ever seen twice in their lifetime, once when they are installed and once when they eventually need replacing (which can be up to 20yrs.)
Filters
-
Original price £2,515.70 - Original price £2,515.70Original price£2,515.70 £3,018.84 (inc. VAT)£2,515.70 - £2,515.70Current price £2,515.70 £3,018.84 (inc. VAT) £3,018.84 (inc. VAT)| /
Tsurumi NK High Head Submersible Water Pump
- Fantastic performance in harsh conditions
- High-performance motor
- Can pump high volumes
The NK is a single-phase drainage pump capable of large flows at high heads. Constructed in superior grade materials throughout they give exception...
View full detailsOriginal price £2,515.70 - Original price £2,515.70Original price£2,515.70 £3,018.84 (inc. VAT)£2,515.70 - £2,515.70Current price £2,515.70 £3,018.84 (inc. VAT) £3,018.84 (inc. VAT)| / -
Original price £776.10 - Original price £810.46Original priceFrom £776.10 £931.32 (inc. VAT)£776.10 - £810.46Current price £776.10 £931.32 (inc. VAT) £931.32 (inc. VAT)| /
Tsurumi HSD2.55S Submersible Pump
- Wear resistant
- High-performance motor
- Automatic or manual operation
The HSD2.55S is a robust and lightweight single-phase drainage pump, with an agitator and impeller in chromium iron to minimise clogging and increa...
View full detailsOriginal price £776.10 - Original price £810.46Original priceFrom £776.10 £931.32 (inc. VAT)£776.10 - £810.46Current price £776.10 £931.32 (inc. VAT) £931.32 (inc. VAT)| / -
Original price £39.20 - Original price £705.60Original priceFrom £39.20 £47.04 (inc. VAT)£39.20 - £705.60Current price £39.20 £47.04 (inc. VAT) £47.04 (inc. VAT)| /
Umbra Pompe Acuasystem 2AL Rainwater and Dry Submersible Pump
- Perfect for harvesting and wet areas
- Excellent durability
- Portable submersible pumps
The Acuasystem are multi-stage pumps that can be used as submersibles in rainwater harvesting systems and wells, and also on the surface, or "dry m...
View full detailsOriginal price £39.20 - Original price £705.60Original priceFrom £39.20 £47.04 (inc. VAT)£39.20 - £705.60Current price £39.20 £47.04 (inc. VAT) £47.04 (inc. VAT)| / -
Original price £580.20 - Original price £790.90Original priceFrom £580.20 £696.24 (inc. VAT)£580.20 - £790.90Current price £580.20 £696.24 (inc. VAT) £696.24 (inc. VAT)| /
Umbra Pompe Acuabig Submersible Well Borehole Pump
- 5\" borehole pump
- Suitable for potable water
- Stainless steel body
If you're looking for a bore-hole, multi-stage pump, then this range of ACUABIG pumps from Umbra Pompe could be the ideal solution. If a large flow...
View full detailsOriginal price £580.20 - Original price £790.90Original priceFrom £580.20 £696.24 (inc. VAT)£580.20 - £790.90Current price £580.20 £696.24 (inc. VAT) £696.24 (inc. VAT)| / -
Original price £513.50 - Original price £690.80Original priceFrom £513.50 £616.20 (inc. VAT)£513.50 - £690.80Current price £513.50 £616.20 (inc. VAT) £616.20 (inc. VAT)| /
Umbra Pompe Acuasub Submersible Well Borehole Pump
- High head pump
- Suitable for pumping potable water
- Excellent wear resistance
This series of multi-stage pumps from Umbra Pompe are used in both agricultural and industrial settings. The ACUASUB pumps are perfect for pumping ...
View full detailsOriginal price £513.50 - Original price £690.80Original priceFrom £513.50 £616.20 (inc. VAT)£513.50 - £690.80Current price £513.50 £616.20 (inc. VAT) £616.20 (inc. VAT)| / -
Original price £480.20 - Original price £611.50Original priceFrom £480.20 £576.24 (inc. VAT)£480.20 - £611.50Current price £480.20 £576.24 (inc. VAT) £576.24 (inc. VAT)| /
Tsurumi 50PNI2 Auto Submersible Drainage Pump
- Portable submersible pumps
- Manual or auto models available
- Perfect for sewage, drainage and dirty water
Perfect for sewage and draining, the 50PNI2 are manufactured by Tsurumi Pump, they come with GFRP (Glass fiber-reinforced polymer, vortex impellers...
View full detailsOriginal price £480.20 - Original price £611.50Original priceFrom £480.20 £576.24 (inc. VAT)£480.20 - £611.50Current price £480.20 £576.24 (inc. VAT) £576.24 (inc. VAT)| / -
Original price £475.30 - Original price £510.60Original priceFrom £475.30 £570.36 (inc. VAT)£475.30 - £510.60Current price £475.30 £570.36 (inc. VAT) £570.36 (inc. VAT)| /
Speroni 304 Stainless steel SXS
- Portable submersible pumps
- Manual or auto models available
- Perfect for sewage, drainage and dirty water
SXS pumps in 304 stainless steel and NBR, have a horizontal outlet and a wide pump casing for pumping waste containing fibrous material and suspend...
View full detailsOriginal price £475.30 - Original price £510.60Original priceFrom £475.30 £570.36 (inc. VAT)£475.30 - £510.60Current price £475.30 £570.36 (inc. VAT) £570.36 (inc. VAT)| / -
Original price £39.00 - Original price £39.00Original price£39.00 £46.80 (inc. VAT)£39.00 - £39.00Current price £39.00 £46.80 (inc. VAT) £46.80 (inc. VAT)| /
Stream SPA Submersible Water Pump
- Universal fittings of 32mm, 25mm, and 19mm
- Can handle liquids up to 35°C
Perfect for emptying water fast and efficiently, can be submerged up to 5 meters of water making it great for smaller sump and water tanks. This pu...
View full detailsOriginal price £39.00 - Original price £39.00Original price£39.00 £46.80 (inc. VAT)£39.00 - £39.00Current price £39.00 £46.80 (inc. VAT) £46.80 (inc. VAT)| /
