Tsurumi TDS Petrol Trash Pump

Tsurumi TDS Petrol Trash Pump | Honda Powered Engine Pump for Construction and Site Drainage

The Tsurumi TDS petrol trash pump is a Honda powered, self priming engine pump built to shift dirty water on construction sites, hire fleets, drainage works and flood response jobs. Available in TDS-50HA and TDS-80HA outlet sizes, the TDS range delivers reliable performance where mains power is not available and where the water carries grit, silt and small debris.

What is the Tsurumi TDS pump used for?

•    Site dewatering on construction and civils projects
•    Hire fleets and contractor dewatering
•    Drainage and utilities work
•    Pumping water containing suspended solids up to 20 mm
•    Flood response in locations without mains power
•    Filling and emptying tanks where high flow is required

Construction and Durability

The TDS range is built around a Honda OHV petrol engine housed in a robust steel roll frame fitted with anti vibration rubbers, protecting the pump head during transport and on rough ground. The semi trash design uses elongated bolts through the pump housing so the casing can be opened quickly for inspection or to clear blockages. Tsurumi engineering means the pump is built to last on demanding sites, and the Honda Oil Alert system shuts the engine down to protect it if the oil level drops too low. The TDS will handle solids up to 20 mm without the need for a strainer to remove them, giving an extra 12 mm of free passage compared with many Koshin equivalents.

Why choose the Tsurumi TDS?

Tsurumi has built its reputation on heavy duty submersible and engine pumps that survive years of hire fleet use. The TDS gives contractors a self priming pump with high flow, reliable Honda starting and a service friendly design where the impeller and volute can be reached without specialist tools. Suction lift is rated to 6 metres and up to a maximum of 8 metres, and all the everyday accessories you need to put the pump to work are included in the box. If you want a workhorse trash pump that earns its keep on hire and project sites, the TDS is a strong choice.

Operational Details

•    TDS-50HA: 50 mm inlet and outlet, Honda GX120 engine, 4.0 HP, flow up to 780 l/min, head 23 m
•    TDS-80HA: 80 mm inlet and outlet, Honda GX160 engine, 5.5 HP, flow up to 1,150 l/min, head 23 m
•    Fuel: unleaded petrol
•    Free passage (solids handling): up to 20 mm
•    Suction lift: 6 metres recommended, 8 metres maximum
•    Self priming
•    Engine protection: Honda Oil Alert low oil shutdown
•    Dry weight: 24 kg (TDS-50HA) or 27 kg (TDS-80HA)

What's in the box

•    1 x Tsurumi TDS pump
•    Hose couplings
•    Suction strainer
•    Manufacturer documentation
