Our 150mm (6 inch) layflat hose is the largest discharge hose we supply, matched to the 6 inch ports on high capacity diesel and electric pumps used in major flood events, quarry dewatering and watercourse over-pumping. Even at this bore it weighs only 0.90 kg per metre, so a single operative can position runs that would need a team and lifting kit with rigid 6 inch hose.
The heavy yarn reinforcement holds the 3 bar working pressure across very high flows, making it the practical choice for moving thousands of litres a minute from flooded sites, excavations and settlement lagoons to a distant discharge point. Between jobs it rolls flat onto a reel for compact storage. For the suction lift into these large pumps, complete the system with our 150mm suction and delivery hose. Coils from 6m to 100m.
Lay flat hose has a maximum working temperature of 60° and a minimum of -15°C
| Nominal size | 150mm |
|---|---|
| Inch equivalent | 6 inch |
| Actual internal bore | 152mm |
| Outside diameter | 154.8mm |
| Wall thickness | 1.4mm |
| Working pressure | 3 bar |
| Burst pressure | 9 bar |
| Weight per metre | 0.900 kg/m |
| Coil lengths | 6, 10, 20, 30, 50, 100mtrs |
